Mooney viscosity tells you how thick, resistant-to-flow an uncured rubber compound or raw polymer is under standardized shear and temperature conditions.

Higher Mooney → stiffer, harder to process
Lower Mooney → softer, easier to mix and shape

Video by MonTech:

What Mooney testing measures

Mooney viscosity is measured using a Mooney viscometer, which consists of:

• A heated die cavity (usually 100 °C)

• A rotating serrated metal disk (the rotor)

• Rubber placed around the rotor

As the rotor turns at a fixed speed, the instrument measures the torque required to rotate it. That torque is converted into a Mooney unit (MU).

Standard test notation

Results are reported in a specific format, for example:

ML(1+4) 100 °C = 65

Meaning:

• M = Mooney

• L = Large rotor (there’s also a small rotor, S)

• 1 min preheat

• 4 min measurement

• 100 °C test temperature

• Result = 65 Mooney units

What changes the Mooney viscosity

Mooney viscosity reflects several molecular and formulation factors:

Polymer-related

• Molecular weight (primary driver)

• Molecular weight distribution

• Branching

• Polymer type (NR, SBR, BR, EPDM, etc.)

Compound-related

• Filler loading

• Plasticizers and oils

• Resins

• Processing aids

• Temperature sensitivity

Because of this, Mooney viscosity is often used as a quality-control fingerprint.

Why it matters in processing

Mooney viscosity strongly affects:

• Mixing energy and temperature rise

• Extrusion quality

• Calendering behavior

• Mold filling

• Dimensional stability

Examples:

• Too high → poor flow, high energy consumption, surface defects

• Too low → sagging, poor shape retention, weak green strength

Mooney relaxation & scorch

The Mooney test can also be extended beyond a single number:

Mooney relaxation

• Rotor is stopped after measurement

• Torque decay is recorded

• Provides insight into elastic recovery and molecular structure

Mooney scorch (MS)

• Measures time to viscosity rise due to early crosslinking

• Critical for processing safety

• Often reported as t₅ or t₃₅ (time to 5 or 35 MU increase)

Limitations

• It’s a single-point, low-shear test

• Doesn’t fully represent high-shear processes (extrusion, injection)

• Not a true viscosity in the rheological sense

• Best used comparatively, not absolutely

Where it fits with other rubber properties

• Mooney viscosity → processability (uncured)

• Payne effect → filler network behavior (dynamic, small strain)

• Mullins effect → stress softening (large strain, cured rubber)

Together, they give a pretty complete picture of how a rubber compound behaves from mixing to service.
